bellshire::Utilities Class Reference

More...

#include <BT_MatML_Utilities_GUI.h>

Inheritance diagram for bellshire::Utilities:

Public Member Functions
void	CollectBranchMaterials (boost::shared_ptr< MatML_Doc > doc, Material *m, std::vector< Material * > &ms)
	Collect Branch of Materials More...
void	CollectBranchMaterialsBackwards (Material *m, std::vector< Material * > &ms)
	Collect Branch of Materials in the Backwards direction More...
void	CollectBranchMaterialsForewards (boost::shared_ptr< MatML_Doc > doc, Material *m, std::vector< Material * > &ms)
	Collect Branch of Materials in the Forwards direction More...

Static Public Member Functions
static wxTreeItemId	MatMLtoTreeCtrl (TreeCtrlSorted *MatMLTreeCtrl, Material *MatMLMaterial)
	Searches the TreeCtrl to find the MatML Element More...
static std::list< std::pair< Material *, xml_schema::string > >	GetMaterialIDPair (::boost::shared_ptr< MatML_Doc > MatMLDoc, std::list< xml_schema::string > ClassFilters=std::list< xml_schema::string >())
	Gather Material* and Material->ID paired together in a list. More...
static bool	InFilter (Material *material, std::list< xml_schema::string > Filter)
	Determines if the Material has a Class->Name for each of the ClassFilter strings If the filter is empty then the default is true. More...
static bool	InFilter (Material *material, xml_schema::string *Filter)
	Determines if the Material has a Class->Name that matches the ClassFilter string More...
static std::list< Name * >	GetMatMLDocClassNames (::boost::shared_ptr< MatML_Doc > MatMLDoc)
	Gathers within the MatMLDoc all of the materials->BulkDetails->Class->Name More...
static std::list< Name * >	GetBulkDetailsClassNames (Material *material)
	Get the Materials BulkDetails->Class->Names More...
static bool	CompareName (Name *&first, Name *&second)
	Comparision of the First Name to the Second Name More...
static bool	SameName (Name *&first, Name *&second)
	Compare if the First Name and Second Name are the same a binary predicate implemented as a function More...
::std::string	Label (::std::string name, ::std::string id)
	Creates a string of the Labels used in wxWidgets displays More...
::std::string	LabelToId (::std::string label)
static std::list< xml_schema::string >	wx2std (const wxArrayString &wxstr)
	Converts wxArrayString to std::list of xml_schema::string More...
static wxArrayString	std2wx (const std::list< xml_schema::string > &stdstr)
	Converts list of xml_schema::string to wxArrayString More...

Detailed Description

Utility Functions

Member Function Documentation

CollectBranchMaterials()

void Utilities::CollectBranchMaterials	(	boost::shared_ptr< MatML_Doc >	doc,
		Material *	m,
		std::vector< Material * > &	ms
	)

Collect Branch of Materials

Parameters

m
ms

CollectBranchMaterialsBackwards()

void Utilities::CollectBranchMaterialsBackwards	(	Material *	m,
		std::vector< Material * > &	ms
	)

Collect Branch of Materials in the Backwards direction

Parameters

m
ms

CollectBranchMaterialsForewards()

void Utilities::CollectBranchMaterialsForewards	(	boost::shared_ptr< MatML_Doc >	doc,
		Material *	m,
		std::vector< Material * > &	ms
	)

Collect Branch of Materials in the Forwards direction

Parameters

m
ms

CompareName()

bool Utilities::CompareName ( Name *&  first, Name *&  second  )

static

Comparision of the First Name to the Second Name

Parameters

first
second

Returns

GetBulkDetailsClassNames()

std::list< Name * > Utilities::GetBulkDetailsClassNames ( Material *  material )

static

Get the Materials BulkDetails->Class->Names

Parameters

material

Returns

GetMaterialIDPair()

std::list< std::pair< Material *, xml_schema::string > > Utilities::GetMaterialIDPair ( ::boost::shared_ptr< MatML_Doc >  MatMLDoc, std::list< xml_schema::string >  ClassFilters = std::list<xml_schema::string>()  )

static

Gather Material* and Material->ID paired together in a list.

Parameters

MatMLDoc
ClassFilters

Returns

MaterialIDPair

GetMatMLDocClassNames()

std::list< Name * > Utilities::GetMatMLDocClassNames ( ::boost::shared_ptr< MatML_Doc >  MatMLDoc )

static

Gathers within the MatMLDoc all of the materials->BulkDetails->Class->Name

Parameters

MatMLDoc

Returns

InFilter() [1/2]

bool Utilities::InFilter ( Material *  material, std::list< xml_schema::string >  Filter  )

static

Determines if the Material has a Class->Name for each of the ClassFilter strings If the filter is empty then the default is true.

Parameters

material
ClassFilters

Returns

InFilter() [2/2]

bool Utilities::InFilter ( Material *  material, xml_schema::string *  Filter  )

static

Determines if the Material has a Class->Name that matches the ClassFilter string

Parameters

material
ClassFilter

Returns

Label()

std::string Utilities::Label ( ::std::string  name, ::std::string  id  )

static

Creates a string of the Labels used in wxWidgets displays

summary> Takes the Label, used in wxWidgets displays, and pulls out the Id

MatMLtoTreeCtrl()

wxTreeItemId Utilities::MatMLtoTreeCtrl ( TreeCtrlSorted *  MatMLTreeCtrl, Material *  material  )

static

Searches the TreeCtrl to find the MatML Element

Find the associated TreeCtrl

Parameters

MatMLTreeCtrl
material

Returns

Matching TreeCtrlId

SameName()

bool Utilities::SameName ( Name *&  first, Name *&  second  )

static

Compare if the First Name and Second Name are the same a binary predicate implemented as a function

Parameters

first
second

Returns

std2wx()

wxArrayString Utilities::std2wx ( const std::list< xml_schema::string > &  stdstr )

static

Converts list of xml_schema::string to wxArrayString

Parameters

stdstr

Returns

wx2std()

std::list< xml_schema::string > Utilities::wx2std ( const wxArrayString &  wxstr )

static

Converts wxArrayString to std::list of xml_schema::string

Parameters

wxstr

Returns

---

The documentation for this class was generated from the following files:

• C:/Users/paulm/source/repos/BT-MatML-Editor/include/GUI/BT_MatML_Utilities_GUI.h
• C:/Users/paulm/source/repos/BT-MatML-Editor/src/GUI/BT_MatML_Utilities_GUI.cpp
